UNTIL NOW

Achieving all of the required parameters has taken significant design and manufacturing skill and we are proud to say that we have managed to produce the smallest and lightest non-halon extinguisher known to have passed the performance standards for aviation.

SPECIFICATION
2BTP CLEAN AGENT
HEIGHT 350MM
WIDTH 115MM
DIAMETER 106MM
MAX WEIGHT 2.5KG

TESTING AND ACCREDITATION:

Achieved the FFA (Federal Aviation Administration) Minimum Performance Standard


Scenario tested against hidden fires, compatibility and windmilling


UL fire tests completed (USA test standard)


Passed Airbus conformance and compatibility testing


Appointed as an Airbus Supply Partner


Independently tested and certified

ENVIRONMENTAL IMPACT:

AGENT UL 711 RATING TOTAL WEIGHT
(lb)
DIMENSIONS
(HXWXD)
ODP GWP (100 YEAR)
HALON 1211′ 5 BC 3.93 17 X 4.8 X 3.25 7.9 1890
2BTP
(HAFEX)
5 BC 4.66 13.7 X 4.5 X 3.5 0.0028 0.005
2BTP* 5 BC 5.6 15.75 X 5 X 3.5 0.0028 0.005
HALOTRON 1
(HCFC BLEND B)*
5 BC 9.3 15 X 5 X 4.25 0.01 77
FE
(HCFC-236FA)*
5 BC 9.5 15.9 X 8 X 4.5 0 9820
FM
(HCFC-227EA)*
5 BC 9.8 16.9 X 6.5 X 4.4 0 3580

Presentation of Mike Madden during FAA Systems Meeting in Köln, Germany, May 11-12, 2011: “Halon Replacement for Airplane Portable Fire Extinguishers – Progress Report”, File: Madden-0511-BTP.pdf

The following slides from the AMPAC Presentation at the FAA Conference in December 2013 clearly show the overall environmental benefits of BTP compared with both Halon 1211 and alternative agents:


CONTACT US

If you are interested in this product or if you’d like something
bespoke to your requirements, we’d love to hear from you.
Contact Stephen Ward, Managing Director at:

T: 01278 727 460

E: stephen@extinguish-ltd.com
